The Measured Plan
From$300
- As-built floor plan, one level up to 1,500 sq ft
- Full dimension strings, wall weights, door and window tags
- One round of revisions included
- DWG + PDF
Typically 3 business days.
Quote my measured planRemote CAD & construction drafting · New Rochelle, NY
By next month, the plan examiner has nothing to send back.
Palladian Drafting Co. of New Rochelle, New York prepares permit-ready CAD drawing sets — as-built floor plans, elevations and framing details — from the hand sketches and field measurements that residential architects and builders send us. One flat fee per project, from $300 to $1,500, quoted before the first line is drawn.
Studio hours Mon–Fri 11am–7pm · evenings by appointment
Flat fee$300–$1,500
The sheet set
A permit set, read sheet by sheet
$300
The floor of our fee schedule: a measured as-built plan, drawn and delivered at one flat price. The largest full permit set with framing is capped at $1,500.
- As-built floor plansMeasured from your field notes and reconciled room by room, closed to the exterior dimension.
- Exterior elevationsFour faces, grade lines, roof pitch and opening heights, annotated to your finish schedule.
- Framing details & sectionsJoist, rafter and header layouts with member callouts for the engineer of record to confirm.
- Title blocks & sheet indexUniform numbering, scale notation and reserved code-note areas where the plan reviewer looks first.
A drawing set is a set of instructions for people who were not in the room. We draw for them.
The Palladian house standard
Drawn for your seal
Palladian draws. Your architect or engineer of record seals.
We do not stamp, and we do not pretend to. Every set is formatted so the licensed professional on your project can review, mark up and file it.
- Sheet index and title block set up for plan-reviewer reading order
- Scale notation and North arrow on every plan sheet
- Files delivered as layered DWG and PDF; the drawings are yours
- Sheet conventions that Westchester and New York City reviewers expect
The fee schedule
Three drawing sets, priced before the first line is drawn
Each fee is flat and written into the quote. Footage bands are stated plainly; anything larger or stranger gets a quote of its own.
Plan & Elevations
Flat$745
- Existing and proposed floor plans, up to two levels
- Four exterior elevations with roof pitch and opening heights
- Title block, sheet index, scale notation
- One round of revisions included
Typically 5 business days.
Order the plan & elevationsThe Permit Set with Framing
Up to$1,495
- Everything in Plan & Elevations
- Building and wall sections
- Floor, roof and header framing details
- Sets up to 3,000 sq ft; above that, a written quote
Typically 7 to 9 business days.
Request the permit set- Extra revision round · $85
- For changes after your first markup is returned.
- Site plan sheet · $120
- Lot lines, setbacks and structure footprint from your survey.
- 48-hour rush · +$150
- Moves your set to the front of the board, subject to availability.
Field notebook to filing counter
What happens between your sketch and the stamped set
I.
Send what you already have
A photographed sketch is enough to begin. We read your handwriting, your abbreviations and your shorthand for existing walls, and we ask once, in a single consolidated list, for whatever is missing.
- A photo or scan of the sketch, held flat and square to the camera
- Field dimensions, even if scribbled in the margins
- The site address and the building department that will review it
- Any survey, prior permit drawing or deed plot you hold
II.
We draw in layers and check against your notes
The plan is built in discrete CAD layers — structure, dimensions, annotation — then each dimension string is reconciled against your field figures. Where two measurements disagree, we flag the pair rather than split the difference.
Our reviewer closes every set against the overall exterior dimension before it leaves New Rochelle.
III.
You receive sheets ready for a seal
The finished set arrives as layered DWG and print-ready PDF. Your markup comes back to us once, at no charge; further rounds are $85 each. We invoice after you approve the set, not before.
Start with your sketch →Before you commit
Questions drafters are asked first
Anything not covered here: contact@palladiandraftingcoremote.com
Do you stamp the drawings?
No. Palladian prepares the drawings; the architect or engineer of record on your project reviews, seals and files them. We format every set for that hand-off.
How is the flat fee fixed?
You send the sketch, address and scope. We return a written quote between $300 and $1,500 that names the sheets included. The number on the quote is the number on the invoice unless you change the scope.
What if my field measurements have gaps?
We list every missing or conflicting dimension in one message and hold the drawing until you answer. Small gaps are usually closed with a phone photo and a tape.
How long does a set take?
A measured plan is typically three business days; a plan with elevations five; a full permit set with framing seven to nine. The 48-hour rush option is $150 when the board has room.
Who owns the files?
You do. Layered DWG and PDF are delivered with the final invoice, and we do not reuse your project drawings for anyone else.
